| | Parameter | ETCITC-108-A | ETCITC-108-B |
| Detector Data | Type | Uncooled FPA |
| | IR Resolution | 384 × 288 | 640 × 480 |
| | Pixel Pitch | 17 µm |
| | Spectral Range | 7.5–14 µm |
| | NETD/Sensitivity | 25 mK |
| Lens Data | FOV | 24° × 18° |
| | Minimum Imaging Distance | 0.3 m |
| | IFOV | 1.13 mrad | 0.68 mrad |
| | Focus | Manual / Motor / Continuous Autofocus / Laser-Assisted Focusing |
| | Lens Recognition | Automatic |
| | Lens (Optional) | 48° × 36°, 12° × 9° |
| | Lens Rotation | 180° rotation |
| Image Performance | Display | HD 5″ Touch AMOLED, 1280×720 |
| | Viewfinder | 0.5″ Color OLED, Manual Zoom, 1920×1080 |
| | Visual Camera | 13 MP CMOS, Autofocus, LED Fill Light |
| | Frequency | 50 Hz / 60 Hz |
| | Amplification | 1×–35× Continuous |
| | Palette | 12 Palettes (Iron Red, Rainbow, Black Hot, White Hot, etc.) |
| | Brightness | Auto / Manual |
| Measurement | Temperature Range | -20°C to +600°C (extendable to 1700°C) |
| | Measurement Accuracy | 5°C–150°C: ±1°C or ±1% of reading; other ranges: ±2°C or ±2% of reading (whichever is larger) |
| | Measurement Mode | Real-time: 20 movable spots, 10 movable rectangular areas, and 10 circular areas (max/min/avg temp measurement). Includes line temp, isothermal analysis, temp difference measurement, and temp alarm (sound/color). |
| | Measurement Correction | Auto / Manual |
| | Emissivity Correction | Adjustable from 0.01 to 1.0 or selected from material list |
| | Background Temperature Correction | Auto (based on input background temperature) |
| | Atmospheric Transmissivity Correction | Auto (based on input distance, relative humidity, and ambient temperature) |
| | Setting Functions | Date/time, temperature unit (°C/°F/K), language |
| Alarm | Sound and Light Alarm | Yes |
| Image Storage | Memory Card | 64 GB |
| | Single Frame Infrared Image Format | JPEG with 14-bit measured data |
| | Single Frame Visible Image Format | JPEG or stored with single frame image |
| | Text Annotation | Supports 30 editable preset text annotations |
| | Voice Annotation | 60-second voice recording per image (built-in microphone) |
| Laser Indicator | Grade / Type | Class 2, 1 mW, 650 nm (Red) |
| | Laser Ranging | Measuring distance: 0.2 m – 50 m |
| Interfaces | Power Interface | Yes |
| | SD Card Slot | Yes |
| | Video Output | HDMI |
| | Audio Output | Yes |
| | USB Interface | USB Type-C (data transmission, radiometric video streaming) |
| | Wi-Fi | Yes |
| | Bluetooth | Yes |
| | GPS | Yes |
| | Compass | Yes |
| | Tripod | 1/4″, _20 |
| Power System | Battery Type | Lithium battery (rechargeable) |
| | Battery Operating Time | 4 hours continuous (at room temperature) |
| | External Power | DC: 5V |
| | Charging System | Two-seater charger or in-camera charging |
| | Power Saving | Yes |
| Environmental Parameters | Operating Temperature Range | -20°C to +50°C |
| | Storage Temperature Range | -40°C to +70°C |
| | Humidity | ≤95% (non-condensing) |
| | Vibration | 2G (IEC60068-2-6) |
| | Shock | 25G (IEC60068-2-29) |
| | Enclosure Rating | IP54 (IEC60529) |
| Physical Data | Size | 183 mm × 160 mm × 88 mm |
| | Weight | ≤1.4 kg (including battery and standard lens) |
| Packing | Standard Accessories | Thermal imaging camera, 2 lithium batteries, battery charger, adapter, USB cable, SD card, HDMI cable, SD card reader, USB flash drive, warranty card, calibration book, carrying case, user manual |
| Quality Assurance | Certification | CE |
