Features
- High-precision pressure sensor ensures the precision and reproducibility of test.
- High-definition LCD is adopted, the display contents are rich; users can enjoy intelligent operations according to the screen tips, Chinese character hint and quantitative index are provided for each operational process.
- Optional for measuring mode: Manual single tablet/automatic continuation.
- The system can realize automatic tablet compressing, automatic display, automatic latching, automatic reset, automatic cycle test, automatic linear error correction, and automatic fault diagnosis.
- Strong data processing ability; statistics, analysis, printing, and display are available for test result. It can submit the reports of maximum and minimum values, standard deviation, and range of change of the test sample.
- Automatic calculation of tablet return travel can compress your test duty time.
- One-key conversion of measuring unit (Newton-Kilogram)
- New type front paper changes mini-printer.
- Convenient and efficient measurement of tablet diameter.
Technical Specifications
| Specification | Details |
| Hardness Test Range | 2–200N (0.2kg–20kg) [Equipped with 500N (50kg) sensor] |
| Resolution | 0.1N / 0.01kg |
| Measurement Accuracy | ±0.5% of range |
| Tablet Diameter Range | 2mm–40mm |
| Repeated Measurement Error | ±1% |
| Batch Testing Capacity | ≤ 100 tablets per group |
| Measuring Units | Newton (N), Kilogram-force (kgf) [1kgf = 9.81N] |
| Interface & Output | Standard serial printing interface with built-in micro-printer |
| Overall Dimensions | 500mm × 400mm × 160mm (L × W × H) |
