Overview
Enviro Test Consrtuct ultrasonic thickness measuring meter is suitable for measuring the thickness of metals, plastics, ceramics, glass, fiberglass and any other good conductors of ultrasonic wave. It can be widely used in petroleum, chemical industry, metallurgy, shipbuilding, aviation, aerospace and other fields.High-precision thickness measurement: it has the functions of zero-point calibration and two-point calibration of probe, which can automatically correct the system error. According to the known thickness, the sound velocity can be measured back to improve the measurement accuracy.
Technical Specifications
| Working principle | Ultrasonic wave (pulse-echo) |
| Detection range | 0.02 in to 11.81 in (0.75 mm to 300 mm) |
| Scan mode | 25 times/second |
| Frequency bandwidth | 0.5 MHz to 15 MHz |
| Speed of sound | 1000 m/s to 9999 m/s |
| Optional probe | High temperature/thin wall coarse grain/ small diameter |
| 2.4 in HD colour screen | High contrast 320 pixels x 240 pixels true colour LCD screen |
| Sound path correction | Automatic |
| Probe connection status indication | Have |
| Storage | TF card machine storage, can be exported to save |
| Communication | USB interface communicates with host computer |
| Dimensions | 5.7 in x 2.9 in x 1.06 in (145 mm x 75 mm x 27 mm) |
