Overview
Enviro Test Construct ultrasonic crack & flaw detector is a collection of portable and fully-digital ultrasonic flaw detectors. The two models in the series-high version and low version-all have the capacity to detect, localize and evaluate various defects in metals with rapidity and precision. Particularly, it is highly effective in the detection of welds, cracks, inclusions, and metal porosity in a non-destructive manner that is suitable for laboratory or project site environments. The detector’s wide variety of applications can be highly useful for defect detection and quality control in manufacturing, steel metallurgy, metal processing and chemical engineering, among other industries. Moreover, it can also be widely used for in-service safety inspections and live assessments in aircraft, railway and traffic industries, as well as boiler and pressure vessels.
Technical Specifications
| Testing range | 0 in x 393.6 in (0 mm to 9999 mm) 0 in x 984.2 in (0 mm to 25000 mm) |
| Velocity | 1000 m/s to 9999 m/s 200 m/s to 20000 m/s |
| Gain | 0 dB to 110 dB |
| Display Delay | -15 μs to 3400 μs |
| Probe Delay | 0 μs to 1000 μs |
| Frequency Noise Level | 0.2 MHz to 15 MHz 0.2 MHz to 20 MHz <10% |
| Probe Damping | 50ohm, 75ohm, 150ohm, 500ohm |
| Resolution | >40 dB |
| Vertical Linearity Error | ≤3% |
| Horizontal Linearity Error | <0.1% |
| Dynamic Range | ≥32 dB |
| Temperature | 14 °F to 122 °F(-10 °C to 50 °C) °F |
| Environment Humidity | 20% RH to 95% RH |
| Working Hours | ≥20 hrs |
| Size | 8.6 in x 6.8 in x 2.3 in (220 mm x 175 mm x 59 mm) |
| Weight | 2.8 lb (1.3 kg) including battery |
