Features
- Precision with Pressure Resistance
- High Synchronous Sampling Frequency
- Extremely Low Power Consumption
- Customizable Functions (e.g., dissolved oxygen, turbidity)
- Customizable Conductivity and Pressure Ranges
- Automatic Temperature Compensation
- 12 V DC Power Supply
- Accurate Measurements with Resolution of 1uS/cm
- RS485 Signal Output with MODBUS-RTU
Technical Specifications
| Conductivity Range | 0 mS/cm to 200 mS/cm (Customizable) |
| Pressure Range | 0 m to 200 m (Customizable) |
| Temperature Range | 0 °C to 60 °C (32 °F to 140 °F) |
| Accuracy | EC: 2%; P: ±0.5%; Temp: ±0.5 °C (±0.9 °F) |
| Resolution | 1 µS/cm |
| Signal Output | RS485 (MODBUS-RTU) |
| Temperature Compensation | Automatic |
| Power Supply | DC 12 V |
| Cable Length | 393 in (10 m) |
| Pressure Rating | (0 to 200) meters (0 in to 7874 in) (Customizable) |
| Shell Material | Stainless Steel + POM |
| Thread | NPT3/4 |
| IP Rating | IP68 |
| Working Temperature | 0 °C to 60 °C (32 °F to 140 °F) |
| Dimensions (inch) | 2.36 in x 10.08 in (60 mm x 256 mm) |
| Weight (lb) | 3.64 lb (1.65 kg) |
