Overview
Enviro Test Construct moisture tester moisture content analyzer adopts a grating infrared moisture meter, and its stability is much higher than that of six beams and eight light speeds. The average test accuracy can reach about 0.1% to 0.5% (depending on the tested material), which meets the requirements of production process. In addition, the infrared moisture meter can quickly and continuously measure on the conveyor belt, and non-contact the measured material, realize online dynamic real-time detection. the reaction time is only 8 ms, and realize the real-time control of the product moisture content.
Features
- Infrared moisture measurement
- Multi-channel settings
- One instrument measures various material
- Stable, unaffected by external factors
- Easy installation, quick operation
- Swift calibration via predetermined marks; user-friendly
Technical specifications
| Suitable for Measuring Materials | White, yellow and other bright colors |
| Wavelength | 1940 nm, 1818 nm dual wavelength detection |
| Probe Glass | The light-emitting glass adopts high-bay quartz glass to avoid stains and moisture adhesion. |
| Measuring Range | 0% to 95% |
| Measurement Accuracy | ±0.2% to ±0.01% (absolute value) |
| Resolution | 0.01% |
| Light Spot | 2.36 in to 1.57 in (40 mm to 60 mm) |
| Measuring Speed | 0.01 s |
| Detector | Add filter package to avoid external light interference |
| Calibration and adjustment | Quick calibration, pre-calibration, no need for daily calibration |
| Filter time | Linear or exponential (0.1-180 secs) |
| Signal output | RS232, RS485, 4-20mA analog signal (3 choose 2) |
| Protocol | Can choose free protocol or MUDBUS-RTU protocol |
| Calibration file | 31 calibration files can be stored |
| Operating temperature | -4 °F to 176 °F (-20℃ to 80 ℃) |
| Working distance | 5.9 in to 15.7 in (150 mm to 400 mm) |
| Working power | 220 V, 50 Hz |
| Clean Purge Interface | Diameter of purge port is 6 mm (0.2 in), compressed air is 0.25 MPa |
| Size | 5.12 in x 5.87 in x 10.9 in (130 mm × 149 mm × 277 mm) |
| Weight | 11 lb (5 Kg) |
