Features
- High precision and sensitivity in flaw detection with digital filtering
- HD display with adjustable settings and high-resolution wide screen true color
- Video recording and data storage capabilities for recording flaw detection
- Low power design with reliable performance
- Multiple detection operation functions
- Including wave crest memory
- Automatic calibration function for material sound velocity
- Square wave excitation technology for excellent penetration and signals
Technical Specifications
| Working Principle | Ultrasound (pulse to echo /echo to echo) |
| Working Frequency Range | 0.5 MHz to 20 MHz |
| Pulse Width | Square wave width 30 ns to 1000 ns adjustable, step 0.1 ns |
| Material Sound Velocity | 300 m/s to 15000 m/s |
| Attenuator Error | Every 12 dB ± 1 dB |
| Vertical Linear Error | ≤3% |
| Horizontal Linear Error | ≤0.5% |
| Dynamic Range | ≥30 dB |
| Flaw Detection Margin | ≥65 dB (2.5 Z 20 N probe) |
| Electrical Noise Level | ≤10 (1 MHz % to 4 MHz %) |
| Equivalent Input Noise | <80 Hz to 10 V to 9 V |
| Pules Repetition Frequency | 20 Hz to 1000 Hz, step 1 Hz |
| Pulse Voltage | 25 V to 400 V adjustable, step 25 V |
| Operating Voltage | 12 V (battery, DC) |
| Storage | Expansion TF card, mass storage |
| Physical Dimension | 7.08 in x 5.11 in x 1.57 in (180 mm x 130 mm x 40 mm)(Height x Width x Depth) |
| Weight | 0.17 Ib (750 g) |
