Overview
Enviro Test Construct infrared CO gas analyzer – ± 2 % F.S accuracy uses selective absorption of infrared by gas molecules. S02, NOx, C02, CO, CH4 and other polar molecules have a permanent electric torch, so it has a vibration, rotation, and other structures. According to quantum mechanics, the energy level of splitting can be coupled with the incident characteristic long infrared radiation to produce absorption and different polar molecules are absorbed by different spectral bands.
Features
- Accurate & Resistant
- Stable Infrared Source
- Corrosion-Resistant
- Customizable Output
- Configurable Alarms
- Flexible Communication
Technical Specifications
| Production rate | 100 % |
| Voltage | 110 V to 265 V |
| CO Minimum Range | 0 ppm to 20 ppm |
| CO Maximum Rnge | 0 % to 100 % |
| Accuracy | ± 2 % F.S |
| Repeatability | ± 1 % FS |
| Zero Drift | ± 1 % FS |
| Range Drift | ± 1 % FS |
| Linear Error Limit | ± 1 % FS |
| Dimension | 19.02 in x 11.81 in x 6.97 in (48.3 cm x 30 cm x 17.7 cm) |
| Weight | 8.81 lb (4 kg) |
