Overview
Enviro Test Construct Carbon Monoxide Co Gas Detector is a versatile device designed for rapid detection of gas concentrations, as well as ambient temperature and humidity measurements. It features an alarm function that activates if the readings exceed the predefined limits. The detector is ideal for detecting gas concentrations in pipelines, confined spaces, and atmospheric environments. It is especially useful for identifying gas leakage or high concentration single gas purity where the background gases are nitrogen or oxygen. With the capability to detect over 500 different gases, it offers a comprehensive solution for various industrial and environmental applications, ensuring safety and accuracy in gas monitoring.
Features
- Built-in pumping measurement, integrated water vapor and dust filter
- Rich human-machine interface
- Large-capacity data storage function, support multiple storage methods
- High temperature gas detection (optional)
- Three display modes can be switched
- Graphic display
- Data recovery function
- Using 4500 mA large-capacity rechargeable polymer battery
- Support real-time detection or timing detection
- Mistaken operation recognition function
- Multi-level calibration of target points to ensure linearity and accuracy of measurement
- Zero-point automatic tracking, long-term use will not be affected by zero-point drift
Technical Specifications
| Scope of detection | 0 ppm to 10 ppm, 50 ppm, 100 ppm, 500 ppm, 1000 ppm, 2000 ppm, 5000 ppm, 10000 ppm,20000 ppm ,50000 ppm ,100000 ppm |
| Detection gas | Carbon monoxide CO |
| Resolution | 0.001 ppm, 0.01 ppm, 0.1 ppm, 1 ppm |
| Detection principle | Electrochemical principles |
| Sensor life | 5 years |
| Detection method | Built-in pump suction, flow rate 500 ml/min |
| Display method | 2.31 in high-definition color screen |
| Detection accuracy | < + 3 % F.S |
| Linearity | < + 2 % |
| Alarm method | Sound and light alarm, vibration alarm, visual |
| Response time | < 20 S |
| Power supply | DC 3.6 V |
| Battery capacity | 3.6 VDC, 4500 mA large-capacity rechargeable and short circuit protection functions |
| Relative humidity | < 0 to 99 % RH |
| Data storage | Standard configuration of 100,000 data capacity, support history viewing, deletion or data export, free host computer communication software. The storage function is off by default, and can be set to on, and the storage time interval can be set arbitrarily. |
| Communication Interface | USB (charging and communication), Optional with extra charge RS485 or RS232 |
| Explosion-proof type | Intrinsic safe |
| Protection level | IP65, dust and splash proof |
| Repeatability | < + 2 % |
| Recovery time | < 30 seconds |
| Humidity Measurement | 0 % RH to 100 % RH |
| Accuracy | 3 % RH |
| Temperature | – 40 °F to 158 °F (- 40 °C to 70 °C) |
| Dimensions | 6.29 in x 2.7559 in x 1.10 in (16.0 cm x 7.0 cm x 2.8 cm) |
| Weight | 10.58 oz (300 g) |
