Features
- 384 × 288 Resolution
- 19 mm focal length
- Night search
- Drone search
- Outdoor search and other scenes
Technical Specifications
| Response Waveband | 8 μm to 14 μm |
| NETD | < 35 mk 77 °F (25 °C) |
| Resolution | 384 px × 288 px |
| Frame | 50 fps |
| Pixel Interval | 12 μm |
| No uniformity Correction | Shutter Correction |
| Brightness | Support |
| Contrast | Support |
| DDE | Support |
| AGC Mode | Auto |
| DNR | Support |
| Zoom | × 1，× 2，× 4，× 8 |
| Palette | Black Hot, White Hot, Red Hot, and Fusion |
| DPC | Support |
| CVBS | Support |
| Frame | 50 fps |
| First Image | 6 s |
| Param. Saving | Support |
| Reticle | Support |
| Menu | Support |
| Video Interface | CVBS |
| Communication Interface | UART |
| Battery Sampling Interface | Support (Reserved） |
| Power Supply | USB 5 V 2.5 VDC to 4.2 VDC (Typical: 3.6 VDC) |
| Power Consumption | 0.85 W (with CVBS off) |
| Impact Strength | 26.45 oz / s (750 g / ms) |
| Lens Mount | M25 × 0.01 in (0.5 mm) M34 × 0.02 in (0.75 mm) |
| Working Temperature and Humidity | – 40 °F to 158 °F (- 40°C to 70 °C), < 90 % RH |
| Storage Temperature and Humidity | – 49 °F to 185 °F (- 45 °C to 85 °C), < 90 % RH |
| Weight | < 0.77 oz (22 g) |
