Features
- True RMS capability for accurate readings on non-sinusoidal AC waveforms
- Flexible operation with both automatic and manual range selection
- Inrush current detection, diode test, phase recognition, and continuity testing
- Large digital display for easy, high-resolution measurement visibility
- Wide jaw opening to accommodate larger conductors
- Convenient functions like data hold and low battery indication
- Enhanced safety with built-in overload protection
- Automatic power-off feature to extend battery life
Technical Specifications
| Specification | Details |
| AC Current | 4 A/ 40 A / 400 A / 600 A and Accuracy: ±(2% + 5) |
| DC Voltage | 400 mV / 4 V / 40 V / 400 V / 600 V and Accuracy: ±(0.8% + 2) |
| AC Voltage | 400 mV / 4 V / 40 V / 400 V / 700 V and Accuracy: ±(1.2% + 5) |
| Resistance | 400 Ω / 4 kΩ / 40 kΩ / 400 kΩ / 4 MΩ / 40 MΩ and Accuracy: ±(1% + 3) |
| Capacitance | 10 nF / 100 nF / 1 μF / 10 μF / 100 μF / 1 mF / 10 mF and Accuracy: ±(3% + 5) |
| Frequency | 10 Hz / 100 Hz / 1 kHz / 10 kHz / 100 kHz / 1 MHz / 40 MHz and Accuracy: ±(0.5% + 3) |
| Duty Cycle | 1% to 99% and Accuracy: ±(0.5% + 3) |
| Temperature | -58 °F to 1832 °F (-50 °C to 1000 °C) and Accuracy: ±(1.2% + 6) or ±(1% + 5) |
| Safety Rating | EN61010-1, CAT.Ⅱ 1000 V |
| Power Supply | 2 × AA (1.5 V) |
| Size | 9.80 in × 3.50 in × 1.50 in (249 mm × 89 mm × 38 mm) |
| Weight | 0.79 lb (360 g) |
