Overview
Enviro Test Construct Widely used in Floor maintenance, Surface cleaning quality control, Stone and tile gloss measurement, checking printed matter, Quality control of paint and ink, Polished metal surface, measurement (chrome plating), Inspection of paint protection and waxing, Auto-body paint inspection, Surface inspection of plastic moldings, Evaluation of detergents and washers, Checking masonry and washers, Checking building exteriors.
Features
- Accurate measurement, good repeatability
- Small in size, easy to carry.
- Auto calibration.
- Intelligent design, rapid measurement.
- Able to store 254 groups of measurements.
- Backlight display, suitable for low light environment.
- Use “USB data output” and “RS-232 data output” to connect with PC.
- Provide “Bluetooth ™ Data output” choice.
Technical Specifications :
| Display | 4 Digits Backlit LCD |
| Measuring Geometry | 20/60/85 Degrees (GM-6: 60 Degrees, GM-26: 20 Degrees and 60 Degrees) |
| Range | 0.1 Gu to 200 Gu |
| Gloss Units | GU |
| Accuracy | ±1.0 GU |
| Resolution | 0.1GU |
| Repeatability | ± 0.5GU |
| Measuring Area | 0.27559 in x 0.55118 in (7 mm * 14 mm) (Ellipse) |
| Data Memorized | 254 Groups |
| Working Condition | Temperature: 0 °C to 40°C (32 ℉ to 104 ℉) Humidity: < 85% |
| Power Supply | 3.7 V built-in Lithium Ion Rechargeable Battery |
| Dimensions | 5.51181 in x 1.77165 in x 2.95276 in (140 mm * 45 mm * 75 mm) |
| Weight | 0.67241 lb (0.305 kg) |
| International standard | ASTMD523, ASTMD1455, ASTMC346, ASTMC584, ASTMD2457, DIN ENISO2813, DIN67530, ENISO7668, JISZ8741, MFT30064, TAPPIT480, GB9754, GB/T13891, GB7706 and GB8807, JJG696-2002 |
