Features
- Detects skin-dose (beta particle) and deep-dose (gamma) and X-ray radioactivity
- Requires no adjustments; simple two button process
- Provides promptly read, correct value through auto ranging capability
- Easily visible inside truck trailers and other low-light situations with automated backlight
- Works dependably inside or outside thanks to sealed case
- Delivers more than one week of functioning with two 9 V alkaline batteries
- Measures both dose and dose-rate
Technical Specifications
| Radiation Detected | Beta: >100 keV Gamma: >7 keV |
| Operating Ranges, Response Time | 0 mR/h to 5 mR/h (8 s) 0 mR/h to 50 mR/h (2.5 s) 0 mR/h to 500 mR/h (2 s) 0 R/h to 5 R/h (2 s) 0 R/h to 50 R/h (2 s) |
| Detector | Chamber (cc volume air ionization): 349 cc Chamber wall (phenolic): 246 mg/cm2 Chamber window (mylar): 6.6 mg/cm2 Beta slide: 440 mg/cm2 |
| Power Requirements | Two 9 V alkaline, 200 h operation |
| Temperature Range | -4 °F to 122 °F (-20 °C to 50 °C) |
| Relative humidity | 0 to 100 % (at 140 °F/ 60 °C) Geotropism: < 1 % |
| Dimensions | 4 in x 8 in x 6 in (100 mm x 200 mm x 150 mm) |
| Weight | 2.5 lb. (1.11 kg) |
