| DC V Range |
0 V to 60.00 V (Upper Display ±30 V) |
| DC mA Range |
0 mA to 24.000 mA (Upper Display ±24 mV) |
| DC mV Range |
-15.000 mV to 80.00 mV; 80.00 mV to 125.00 mV |
| Accuracy |
0.05% +2 |
| Resistance (2 wires, 3wires) Range |
0.00 Ω to 440.00 Ω; 400.00 Ω to 3200.00 Ω |
| Resistance (4wires) Range |
0.00 Ω to 440.00 Ω; 400.00 Ω to 3200.00 Ω |
| Accuracy resistance |
0.15 Ω; 1.0 Ω |
| Frequency Range |
1.000 Hz to 99.99 Hz; 1000.0 Hz to 9999.99 Hz; 10.000 kHz to 99.999 kHz |
| Output Index |
| DC mA (Active/Passive) Range |
0 mA to 24.000 mA |
| DC V Range |
0 V to 10.00 V |
| DC mV Range |
-15.00 mV to 99.99 mV; 100.00 mV to 125.00 mV |
| Frequency Range |
0.20 Hz to 200.00 Hz; 200.0 Hz to 2000.0 Hz; 2.000 kHz to 20.00 kHz |
| RTD |
Pt100, Pt1000, Cu50, Cu100 |
| General technical specifications |
| Operating temperature |
14 °F to 131 °F (-10 °C to 55 °C) |
| Storage temperature |
-4 °F to 140 °F (-20 °C to 60 °C) |
| Relative humidity |
0% RH to 90% RH, non-condensing |
| Power supply mode |
6 or 7 batteries or AC adapter |
| Weight |
1.43 lb (650 g) |
| Dimensions |
7.87 in x 3.77 in x 1.85 in (200 mm × 96 mm × 47 mm) |
