Features
- Compact and lightweight handheld design for portability
- Easy-to-read digital display for quick measurements
- Battery-powered operation with built-in power supply
- Rugged construction suitable for industrial applications
- Audio signal detection for added functionality
- Simple one-hand clamp operation for convenience
- Designed for accurate and reliable performance
Technical Specifications
| Clamp Opening Size | 0.18 in (4.5 mm) |
| Max. AC Current | 1000 A ±2.5% |
| Max. DC Voltage | 1000 V ±1.2% |
| Max. AC Voltage | 750 V ±2% |
| Measuring Current Range | 200 A to 1000 A ±2.5% |
| Measuring Resistance Range | 200 Ω to 20 kΩ (20 MΩ to 2000 MΩ) ±2.0% |
| Parameters Measured | AC voltage, AC current, DC voltage, resistance |
| Display Type | Digital only |
| Power Supply Method | 9 V 6F22 battery (built-in), 800 mAh capacity |
| Additional Features | Audio signal detection |
| Testing Speed | Standard mode |
| Accuracy | ±1% |
| Operating Temperature | 50 °F to 104 °F (10 °C to 40 °C) |
| Dimensions | 9.06 × 2.76 in (230 × 70 mm) |
| Weight | 0.79 lb (360 g) |
Reviews
There are no reviews yet.
