| Specification |
Details |
| Infrared Resolution |
256 × 192 |
| Temperature Range |
-4 °F to 1022 °F (-20 °C to 550 °C) |
| Measurement Accuracy |
±3.6 °F (±2 °C) or ±2% of reading |
| Thermal Sensitivity (NETD) |
≤40 mK @ 77 °F (25 °C, F#1.0) |
| Detector Type |
VOx Uncooled Microbolometer |
| Pixel Size |
12 μm |
| Field of View (FOV) |
50° × 37.2° |
| Spatial Resolution |
3.43 mrad |
| Focal Length |
3.5 mm |
| Frame Rate |
25 Hz |
| Focusing Method |
Fixed focus |
| Temperature Units |
°C / °F / K |
| Display Resolution |
Adapts to mobile phone screen |
| Brightness Levels |
5 |
| Temperature Display |
Point temperature, line/surface average, max, min |
| Temperature Analysis |
3 points, 3 lines, 3 regions |
| Isotherm |
Supported |
| High/Low Temp Tracking |
Supported |
| High/Low Temp Alarm |
On-screen marker alarm / Audio alarm |
| Color Palettes |
15 (White Hot, Black Hot, Rainbow, Iron Red, Fusion, etc.) |
| Image Modes |
Infrared, Visible Light, Fusion, Picture-in-Picture |
| Image/Video Recording |
JPEG / MP4 |
| Data Interface |
Type-C |
| Mobile App |
Android 7.0 or above |
| Battery |
1100 mAh Polymer (non-removable) |
| Charging Time |
≤2 h |
| Operating Time |
≥2.5 h |
| Operating Temperature |
14 °F to 122 °F (-10 °C to 50 °C) |
| Storage Temperature |
-4 °F to 140 °F (-20 °C to 60 °C) |
| Operating Humidity |
10% to 90% RH, non-condensing |
| Power Consumption |
≤1.4 W |
| Product Size |
5.38 in × 1.61 in × 0.85 in (136.6 mm × 41 mm × 21.55 mm) |
| Weight |
0.45 lb (205 g) |
| Packaging Size |
6.97 in × 4.61 in × 2.17 in (17.7 cm × 11.7 cm × 5.5 cm) |
| Gross Weight |
1.32 lb (0.6 kg) |
| Accessories |
Colour box, manual, Type-C cable (3.28 ft / 1 m) |
